Virtually Unmatched

With this 90mm Summicron lens light fall-off is very low. Its fast aperture lets you shoot at a relatively short exposure time – even in dim light. The result is a minimized camera shake, even when shooting street scenes from a distance. Thus the APO-Summicron-M 90mm f/2 ASPH. is ideal for photojournalism, theatre and even portrait photography.

Technical Details

Apochromatic colour correction and an aspherical lens surface are combined for the first time in the Apo-Summicron 90mm f/2 ASPH. Of its individual elements, two are made of high-refraction glass, while two others feature anomalous partial dispersion. Its brilliance and quality of resolution are exemplary even at full aperture.

AT A GLANCE

• High-Speed Telephoto with Stunning Subject Separation
• Apochromatic Lens Design
• Built-In Retractable Lens Hood

IN THE BOX

• 90mm APO-Summicron-M f/2 ASPH Lens
• E55 Lens Cap
• Rear Lens Cap M
• Lens Pouch

Angle of view (diagonal, horizontal, vertical):
27°, 23°, 15°

Optical design

Number of lenses/groups:
5 / 5

Focal length:
90.9 mm

Position of entrance pupil:
58.6 mm (related to the first lens surface in light direction)

Focusing range:
1 m to Infinity

Distance setting

Scales:
Combined meter/feet graduation

Smallest object field:
220 mm x 330 mm

Largest reproduction ratio:
1:9

Aperture

Setting/Function:
With click-stops, half values available, manual diaphragm

Lowest value:
16

Bayonet:
Leica M quick-change bayonet with 6 bit lens identification bar code for digital M models

Filter mount:
Internal thread for screw-in type filters E 55

Lens hood:
Built-in, telescopic

Dimension and weight

Length:
78 mm

Largest diameter:
64 mm

Weight:
Approx. 500 g
