Camera type:

Digital camera system with rangefinder

Buffer:

Memory 3 GB

DNG™: 15 recordings

JPG: > 100 recordings

Storage Medium:

UHS-II (recommended), UHS-I, SD/SDHC/SDXC memory card (SDXC cards up to 2 TB, internal memory 64 GB)

Material:

Black: full-metal housing made of magnesium and aluminum, leatherette cover

Lens mount:

Leica M bayonet with additional sensor for 6-bit encoding

Operating conditions:

+0 to +40°C

Interfaces:

ISO accessory shoe with additional control contacts for Leica flash units and Leica Visoflex 2 viewfinder (optional accessory), USB 3.1 Gen1 Typ-C

Tripod thread:

A 1⁄4 DIN 4503 (1⁄4”) with stainless steel in the base

Dimensions:

139 x 38.5 x 80mm

Weight:

Black: approx. 530 g/455 g (with/without battery)

Sensor size:

CMOS sensor, pixel pitch: 3.76 μm, 35 mm: 9528 x 6328 pixels (60.3 MP)

Processor:

Leica Maestro series (Maestro III)

Filter:

RGB color filter, UV/IR filter, no low-pass filter

File formats:

DNG™ (raw data, loss-free compression), DNG + JPG, JPG (DCF, Exif 2.30)

Image resolution:

DNG™

L-DNG 60,3 MP 9528 x 6328 pixels

M-DNG 36,5 MP 7416 x 4928 pixels

S-DNG 18,4 MP 5272 x 3498 pixels

JPG

L-JPG 60,1 MP 9504 x 6320 pixels

M-JPG 36,2 MP 7392 x 4896 pixels

S-JPG 18,2 MP 5248 x 3472 pixels

File size:

DNG™

L-DNG approx. 70–120 MB

M-DNG approx. 40–70 MB

S-DNG approx. 20–40 MB

JPG

L-JPG approx. 15–30 MB

M-JPG approx. 9–18 MB

S-JPG approx. 5–9 MB

Color depth:

DNG™: 14 Bit, JPG: 8 Bit

Color space:

sRGB

Viewfinder:

Large, bright-line rangefinder with automatic parallax compensation, suitable for -0.5 dpt; optional corrective lenses available: -3 to +3 dpt

Display:

Four-digit digital display with items show on the top and bottom, Image field limiter: two lit frames: 35 mm + 135 mm, 28 mm + 90 mm, 50 mm + 75 mm (automatic switchover when lens is attached)

Parallax compensation:

The horizontal and vertical difference between viewfinder and lens is compensated automatically in line with the relevant focus setting. Congruence of viewfinder and actual image. The size of the bright-line frame matches the distance:

– at 2 m: the exact sensor size of approx. 23.9 x 35.8 mm

– at infinity: (depending on focal length) approx. 7.3% (28 mm) to 18% (135 mm)

– less than 2 m: less than sensor size

Viewfinder magnification:

x0.73 (all lenses)

Large-base rangefinder:

Split or superimposed image rangefinder shown as a bright field at the center of the viewfinder image

LCD panel:

2.95” (Active Matrix TFT), Gorilla Glass 5 cover glass, 2,332,800 dots, format 3:2, touch control available

Shutter type:

Electronically controlled focal plane shutter and electronic shutter function

Shutter speeds:

Mech. shutter: 60 min to 1⁄4000 s

Electro. shutter function: 60 s to 1⁄16000 s

Flash Synch: up to 1⁄180 s

Optional noise reduction via additional “black picture” (can be disabled)

Shutter button:

Two-stage (1st stage: activation of the camera electronics including exposure metering and metering memory lock, 2nd stage: taking the picture)

Self-timer:

Delay time: 2 s or 12 s

Image capture:

Single

Continuous - Low Speed (3 fps)

Continuous - High Speed (4.5 fps)

Interval Shooting

Exposure Bracketing

Focus range:

70 cm to ∞

Focus mode:

Manual (focus assist functions Magnification and Focus Peaking available)

Exposure metering:

TTL (exposure metering through the lens)

Metering principle:

Exposure metering is done by the image sensor for all exposure metering methods (in Live View mode and in rangefinder mode)

Exposure metering:

Spot, Center-Weighted, Multi-Field

Exposure modes:

Aperture priority mode (A): Automatic shutter speed control with manual aperture preselection

Manual (M): manual setting for shutter speed and aperture

Exposure compensation:

±3 EV in 1⁄3 EV increments

Automatic bracketing:

3 or 5 shots, graduations between shoots up to 3 EV, in 1⁄3 EV increments, additional optional exposure compensation: up to ±3 EV

ISO sensitivity range:

Auto ISO: IS0 64 (native) to ISO 50 000, also available in flash mode

Manual: ISO 64 to ISO 50,000

White balance:

Automatic (Auto), Default (Daylight - 5200 K, Cloudy - 6100 K, Shadow - 6600 K, Tungsten - 2950 K, HMI - 5700 K, Fluorescent (warm) - 3650 K, Fluorescent (cool) - 5800 K, Flash - 6600 K), manual metering (Gray card), manual color temperature setting (Color Temperature, 2000 K to 11,500 K)

Flash sync time:

1⁄180s, slower shutter speeds available, automatic switchover to TTL linear flash mode with HSS-compatible Leica system flash units if sync time is undercut

Flash exposure metering:

Using center-weighted TTL pre-flash metering with Leica flash units (SF 26, SF 40, SF 58, SF 60, SF 64) or with system-compatible flash units, remote controlled flash SF C1

Flash exposure compensation:

SF 40: ±2 EV in 1⁄2 EV increments

SF 60: ±2 EV in 1⁄3 EV increments

Other: ±3 EV in 1⁄3 EV increments

Display in flash mode (in the viewfinder only):

Flash icon: Connection of an external flash unit

Equipment WLAN:

The Leica FOTOS app is required to use the WLAN function. The Leica app is available from the Apple App Store™ or the Google Play Store™. 2.4 GHz/5 GHz* dual band IEEE802.11 a/b/g/n/ac Wave2 WLAN (standard WLAN protocol), encryption method: WLAN-compatible WPA™/WPA2™, access method: infrastructure mode

Bluetooth*:

Bluetooth v4.2 BR/EDR/LE, BR/DR-channel 1-79, LE-channel 0-39 (2402–2480 MHz)

GPS*:

Geotagging via Leica FOTOS app using Bluetooth

* Available after Firmware Update during second half of 202

Menu languages:

English, German, French, Italian, Spanish, Russian, Japanese, Simplified Chinese, Traditional Chinese, Korean, Portuguese

Rechargeable battery (Leica BP-SCL7):

Li-Ion (Lithium-Polymer) rechargeable battery, rated voltage: 7.4 V / capacity: 1800 mAh, Charging voltage/current: DC 1000 mAh, 7.4 V, operating conditions: +10°C to +35°C (charging) / +0°C to +40°C (discharged)

Charger (Leica BC-SCL7)

Input: USB-C DC 5 V, 2 A, output: DC 8.4 V, 1 A, operating conditions: +10°C to +35°C

Power pack (Leica ACA-SCL7):

Input: AC 110 V - 240 V ~ 50/60 Hz, 0.3 A, output: DC 5 V, 2 A, operating conditions: +10°C to +35°C

USB power supply:

When in standby mode or Off: USB charging function

When On: USB power supply and intermittent charging
